Table B-1 L1745 Specifications (continued)
Operating 0 to 12,000 feet 0 to 3657.6 m
Storage 0 to 40,000 feet 0 to 12192 m
Power Consumption (maximum) <70 watts
Input Terminals One DVI-
D connector with cable included.
One VGA connector with cable included.
Recognizing Preset Display Resolutions
The display resolutions listed below are the most commonly used modes and are set as factory defaults.
This monitor automatically recognized these preset modes and they will appear properly sized and
centered on the screen.
Table B-2 L1745 Model Factory Preset Modes
Preset Pixel Horz Freq Horz Vert Freq Vert Pixel Clk Source
Format (kHz) Polarity (Hz) Polarity (MHz)
1 640 × 480 31.469 − 59.940 − 25.175 VGA
2 640 × 480 37.861 − 72.809 − 31.500 VESA
3 640 × 480 37.500 − 75.000 − 31.500 VESA
4 720 × 400 31.469 − 70.087 + 28.322 VGA
5 800 × 600 37.879 + 60.317 + 40.000 VESA
6 800 × 600 48.077 + 72.188 + 50.000 VESA
7 800 x 600 46.875 + 75.000 + 49.500 VESA
8 832 x 624 49.726 ± 74.551 ± 57.284 Mac
9 1024 × 768 48.363 − 60.004 − 65.000 VESA
10 1024 × 768 56.476 − 70.069 − 75.000 VESA
11 1024 x 768 60.023 + 75.029 + 78.750 VESA
12 1152 x 870 68.680 − 75.060 − 100.000 Mac
13 1152 x 900 71.710 − 76.050 − 105.561 Sun
14 1280 × 1024 63.980 + 60.020 + 108.000 VESA
15 1280 x 1024 79.970 + 75.020 + 135.000 VESA
Entering User Modes
The video controller signal may occasionally call for a mode that is not preset if:
●
You are not using a standard graphics adapter.
●
You are not using a preset mode.
It this occurs, you may need to readjust the parameters of the monitor screen by using the on-screen display
or HP Display Assistant software. Your changes can be made to any or all of these modes and saved in
ENWW R
ecognizing Preset Display Resolutions 33
