LCD Configuration and Status
Displaying the Battery Charge Data
Select Battery Data on the Main Menu to display the amount of charge on the battery in
10 percent increments.
Main Menu
Battery Data
When the UPS goes into Battery mode, the following LCD displays.
Battery Discharge
|❚❚❚ | 1h=❚
The remaining battery energy is shown, where the tag “1h=❚” means that each block
represents one hour. For example, this LCD shows three hours of remaining battery time.
Other possible tags are listed in Table 3-6.
Table 3-6: Possible Tags
Tag Time
1m 1 minute per block
5m 5 minutes per block
10m 10 minutes per block
30m 30 minutes per block
1h 1 hour per block
Setting the Time
Select Set Time from the Main Menu to set the correct time.
Main Menu
Set Time
Setting the Date
Select Set Date from the Main Menu to set the correct date.
Main Menu
Set Date
3-10 HP Uninterruptible Power System R12000 XR Models User Guide
