4026-0XX
5-7
Second Paper Tray Sensor Board (Option)
Controller Board
Connector Pin No. Signal
CN1A Engine Board 1 CHECK2*
2 CHECK1*
3 CHECK0*
4 MM/INCH
5 2NDBIN*
6PSIZEO
7PEMP2
8GND
9+5Vdc
10 NO CONNECTION
11 FEED2*
12 +24 V dc
CN3A Paper Take-up
Solenoid-2ndPaper
Tray (Option)
1+24Vdc
2FEED2*
Connector Pin No. Signal
J5 Operator Panel 1GND
2+5Vdc
3OPDAT
4OPCLK
5OPBTN1
6OPBTN2
