4.11 Firmware Upgrade
Xsense is continually improving the firmware (software programmed on a
PROM) in each of its products. The XRouter Pro is shipped with the most
up-to-date software available at the time of production. If a firmware
upgrade becomes available, it will be posted in the Service and Support
section on our Web site. To upgrade the XRouter Pro, you will need the
TFTP client and the firmware file named “xxxxx.bin.” These two files can
be found on our Web site at
www.macsense.com. The following is the
upgrade procedure. (See Figure 4.11-1)
Figrue 4.11-1
1. Download these two files from our Web site: TFTP client, and
“xxxxx.bin”
NOTE: These files are actually inside a single compressed folder on our web
site. This means that you would only download one file. Once downloaded
and decompressed, a folder will contain the needed files.
2. Double click the Xsense Router Series Updater icon to run the pro-
gram. Enter both the IP address of the XRouter pro into the IP
Field and your password in the Password Field..
3. Click File Name field. A window appears. Select a location of the
firmware file “xxxx.bin”
4. Click Update button to begin the upgrading process. After the
upgrade is complete, reset the XRouter Pro by unplugging the
device and plugging it back in.
31
Chapter 4 - ADVANCED CONFIGURATION
