when operated by a controller. Please refer to the user manuals for specific details on
address and mode setting.
A
DDRESSING
EXAMPLE
Table 5 shows how you could assign addresses for the following Martin equipment.
•4 MX-1s
• 2 Punisher X250s
• 2 RoboScan 812s
•4 CX-2s
• 1 SynchroZap QX250
• 1 6-Channel DMX Switch Pack
Note that the four CX-2s share two sets of control channels and that all fixtures
except the RoboScan 812s have their control channels on a single button.
Button 1 Button 2 Button 3 Button 4 Button 5 Button 6
Low channels
1
MX-1
7
MX-1
13
Punisher
X250
19
Punisher
X250
25
MX-1
31
MX-1
2 8 14 20 26 32
3 9 15 21 27 33
4 1016222834
5 1117232935
6 1218243036
High channels
37
RoboScan
812
43 49
RoboScan
812
55 61
SynchroZap
QX250
67
6 Channel
Switch Pack
38 44
not used
50 56
not used
62 68
39
45
2 CX-2
51 57
2 CX-2
63 69
40 46 52 58 64 70
41 47 53 59 65 71
42 48 54 60 66 72
Table 5: Example (Addresses shaded)
