© National Instruments Corporation 9 NI PXI/PCI-5114 Specifications
Analog Trigger (Edge, Window, and Hysteresis Trigger Types)
Sources CH 0 (front panel BNC connector)
CH 1 (front panel BNC connector)
TRIG (front panel BNC connector)
—
Trigger Level
Resolution
8 bits (1 in 256)
Trigger Level
Range
CH 0, CH 1 TRIG (External Trigger) —
100% FS ±5 V
Edge Trigger
Sensitivity
5% FS up to 100 MHz 0.5 V
pk-pk
up to 100 MHz
Level
Accuracy,
Typical
±5% FS up to 10 MHz ±0.5 V up to 10 MHz
Jitter ≤ 65 ps rms —
Trigger Filters Low Frequency (LF) Reject High Frequency (HF) Reject —
50 kHz 50 kHz
Digital Trigger (Digital Trigger Type)
Sources NI PXI-5114 NI PCI-5114 —
PXI_Trig <0..6> (backplane
connector)
PFI <0..1> (front panel
SMB connector)
PXI Star Trigger (backplane
connector)
RTSI <0..6>
PFI <0..1> (front panel
SMB connector)
Video Trigger (Video Trigger Type)
Sources CH 0 (front panel BNC connector)
CH 1 (front panel BNC connector)
TRIG (front panel BNC connector)
—
Specification Value Comments
