NEC Corporation 1989
Document No. IC-2472B
(O. D. No. IC-7208C)
Date Published November 1993 P
Printed in Japan
DATA SHEET
MOS INTEGRATED CIRCUIT
µ
PD75P308
The mark ★ shows major revised points.
4-BIT SINGLE-CHIP MICROCOMPUTER
DESCRIPTION
The
µ
PD75P308 is a model of the
µ
PD75308 equipped with a one-time PROM or EPROM instead of an
internal mask ROM.
Two types are available as the
µ
PD75P308. The one-time PROM type is ideal for production of a small
quantity of many different types of application systems as data can only be written once to the one-time
PROM of this type. Programs can be written and rewritten to the built-in EPROM type making it ideal
for system evaluation.
Detailed functions are described in the followig user's manual. Be sure to read it for designing.
µ
PD75308 User's Manual: IEM-5016
The function common to the one-time PROM and EPROM types of product is referred to as PROM throughout this document.
The information in this document is subject to change without notice.
FEATURES
•
µ
PD75308 compatible
• Memory capacity
• Program memory (PROM): 8064 x 8 bits
• Data memory (RAM): 512 x 4 bits
• Can be connected to a pull-up resistor through software: Ports 0-3, 6, 7
• Open-drain input/output: Ports 4 and 5
• Single power source: 5V ± 5%
ORDERING INFORMATION
Part Number Package Internal ROM
µ
PD75P308GF-3B9 80-pin plastic QFP (14 x 20 mm) One-time PROM
µ
PD75P308K 80-pin ceramic WQFN (LCC w/window) EPROM
QUALITY GRADE
Part Number Package Quality Grade
µ
PD75P308GF-001-3B9 80-pin plastic QFP (14 x 20 mm) Standard
µ
PD75P308K 80-pin Ceramic WQFN (LCC w/window) Standard
★
Please refer to "Quality Grade on NEC Semiconductor Devices" (Document number IEI-1209) published by NEC
Corporation to know the specification of quality grade on the devices and its recommended applications.
