C3X Lumis HOST
EMAIL SETTINGS
This screen is used to define the operating parameters for
notification of the projector status by e-mail.
Enabled: notification service by email is enabled.
Disabled: notification service by email is disabled.
Domain name, SMTP Mail Server: parameters to be en-
tered according to the specific network settings to which
the C3X Lumis HOST projector is connected.
IMPORTANT:
To save the network settings the projector needs to
be rebooted, set the system to standby and wait for
the cooling sequence to complete. Once the fans
have stopped power off the HOST and Projector via
main power switch. Wait 5 seconds and Power on the
projector and HOST.
Email Configuration
SMTP Mail Server:
172.031.127.066
Domain Name:
Mail Server:
SMTP Port:
00025
Recipient Address:
support@mail.it
Enable Disable
Apply Settings
Factor Settings
IP Address Mode
Web interface
Remote Control
IP Address: 172.031.127.055
Subnet Mask: 255.255.000.000
Gateway: 172.031.045.115
DHCP Host Name : sim2prj
Port: 08080
Password: XXXX
Port 1: 10001
Port 2: 30704
Static IP Dinamic IP (DHCP)
Apply Settings
Factory Settings
DESCRIPTION OF THE NOTIFICATION MAIL SENT BY
THE PROJECTOR
If the email notification service is enabled, the projector will
automatically send an email to the specified address when
the following circumstances occur:
1. Cooling fan error (Error Code 1)
2. Temperature too high (Error Code 2)
3. Lamp error (Error Code 3)
4. Communication error (Error Codes 4 e 5)
Email sender: “CCCCCCCCCCCCCCCCCCCExxx”
C: serial code of the projector sending the notification
X: error code
Email subject: “WWWWWLLLLLFFFFFFXXXYYY#
W: Total hours of projector use
L: Hours projector lamp on
F: Software firmware version
X: Operating status:
0 – OFF
1 – ON
2 – Lamp preheating
3 – Lamp switching back on
4 – Lamp cooling
Y: Specific status:
0 – None
1 – Blank
2 – Freeze
3 – Test Pattern
