C3X Lumis HOST
ELETTRONICS
Input signals:
• 2 COMPOSITEVIDEO (CVBS)
gilded RCA type connectors
1.0 V
pp
/ 75 Ω, negative synchronisation
• 2 S-VIDEO (Y/C)
4 pin mini-DIN connectors
Y: 1.0 V
pp
/ 75 Ω, negative synchronisation
C: 0.286 V
pp
/ 75 Ω, [NTSC burst rated level]
0.3 V
pp
/ 75 Ω [PAL, SECAM burst rated level]
• 1 SETS OF 5 BNC CONNECTORS (YPRPB/RGB)
• 3 SETS OF 5 RCA CONNECTORS (YPRPB/RGB)
- Component signal
Y: 1.0 V
pp
/ 75 Ω,
negative or 3 level synchronisation [HDTV]
PrPb:0.7 V
pp
/ 75 Ω
- RGB Signal
R,B:0.7 V
pp
/ 75 Ω
G: 0.7 V
pp
/ 75 Ω, HV synchronisation
1.0 V
pp
/ 75 Ω,
negative or 3 level synchronisation [HDTV]
Positive or negativeTTL, 5 V
pp
/ 1 kΩ
• 2 RGBHV (RGB analogic)
female DB15HD-type connectors
R,B: 0.7 V
pp
/ 75 Ω
G:0.7 V
pp
/ 75 Ω, separate H, V or HV synchronisation
1.0 V
pp
/ 75 Ω,
negative or 3 level synchronisation [HDTV]
Positive or negativeTTL, 5 V
pp
/ 1 kΩ
• 6 HDMI HDCP
• 1 DVI-D
• 1 SDI
Control: HOST system: Keypad on rear input panel,
emoh ro CP morf 232SR ,lortnoc etomer
automation devices, USB
Projector: Keypad on rear input
panel,
emoh ro CP morf 232SR ,lortnoc etomer
automation devices
Horizontal frequency:
from 15 to 80 kHz (up to UXGA format @ 65 Hz)
Vertical frequency: 24Hz ~ 30Hz - 48Hz ~ 100Hz
Video standard: automatic selection (PAL B,G,H,I,M,N,60,
SECAM, NTSC 3.58 and 4.43)
High definition standard: ATSC HDTV (480p, 720p, 1080i, 1080p)
Graphic standards: VGA, SVGA, XGA, SXGA, UXGA
Colour temperature: from 5500K to 9000K
Outputs: 3 jack connectors (12V 100mA) (1 active
when system powered, 1 active when 16:9
aspect ratio selected, 1 for anamorphic
lens on projector rear panel)
Image shift range: +50% image
14 TECHNICAL SPECIFICATIONS
GENERAL: PROJECTOR
Power cable: (EU, UK and US); 2m long
Power supply: from 100 to 240 VAC, +/- 10% toler-
ance
Frequency from 48 to 62 Hz
Power consumption: 420 W Max
Fuse: FUSE T 10A L H 250V
Dimensions: 458 x 210 x 455 mm (WxHxD)
15,02 x 6,88 x 14,92 inches (WxHxD)
Weight (approx): 11 kg
Operating temperature: 10 to 35°C
Shipping temperature: -15 to 55°C
Storage temperature: -15 to 55°C
Humidity: 20% to 95% without condensation
Safety: EN 60950
Portability: considered “desktop equipment”
Electromagnetic
compatibility: EN 55022 Class B
EN 55024
EN 61000-3-2
EN 61000-3-3
UL approval in progress
Transport: IEC 68-2-31, IEC 68-2-32
GENERAL: HOST
Power cable: (EU, UK and US); 2m long
Power supply: from 100 to 240 VAC
+/- 10% tolerance
Frequency from 48 to 62 Hz
Power consumption: 30W max
Fuse: T 3,15 A H, 5 x 20 mm
Dimensions: 438 x 90 x 301 mm (WxHxD)
14,4 x 32,9 x 11,8 inches (WxHxD)
Weight (approx.): 2,5 Kg
Operating temperature: 10 to 35°C
Shipping temperature: -15 to 55°C
Storage temperature: -15 to 55°C
Humidity: 20% to 95% without condensation
Safety: EN 60950
Portability: considered “desktop equipment”
Electromagnetic
compatibility: EN 55022 Class B
EN 55024
EN 61000-3-2
EN 61000-3-3
UL approval in progress
Transport: IEC 68-2-31, IEC 68-2-32
Manual Version: 460821000 (v1.1)
