– 108 –
The componants identified by
shading and mark
are criti-
cal for safety.
Replace only with part number
specified.
KP-41S5/41S5B/41S5G/
41S5K/41S5R/41S5U
RM-862
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
C824 1-126-964-11 ELECT 10µF 20% 50V
C825 1-104-665-11 ELECT 100µF 20% 25V
C826 1-136-165-00 FILM 0.1µF 5% 50V
C827 1-126-964-11 ELECT 0µF 20% 50V
C828 1-102-824-00 CERAMIC 470pF 5% 50V
C829 1-126-959-11 ELECT 0.47µF 20% 50V
C830 1-102-824-00 CERAMIC 470pF 5% 50V
C831 1-126-960-11 ELECT 1µF 20% 50V
C832 1-126-960-11 ELECT 1µF 20% 50V
C833 1-126-960-11 ELECT 1µF 20% 50V
C834 1-126-968-11 ELECT 100µF 20% 50V
C835 1-126-967-11 ELECT 47µF 20% 50V
C836 1-136-169-00 FILM 0.22µF 5% 50V
C837 1-126-963-11 ELECT 4.7µF 20% 50V
C838 1-104-665-11 ELECT 100µF 20% 25V
C839 1-137-374-11 FILM 0.047µF 5% 50V
C840 1-104-665-11 ELECT 100µF 20% 25V
C841 1-137-374-11 FILM 0.047µF 5% 50V
C842 1-137-374-11 FILM 0.047µF 5% 50V
C844 1-126-933-11 ELECT 100µF 20% 16V
C845 1-126-933-11 ELECT 100µF 20% 16V
C846 1-126-933-11 ELECT 100µF 20% 16V
C847 1-126-933-11 ELECT 100µF 20% 16V
C848 1-126-933-11 ELECT 100µF 20% 16V
C849 1-102-973-00 CERAMIC 100pF 5% 50V
C850 1-102-973-00 CERAMIC 100pF 5% 50V
C851 1-137-374-11 FILM 0.047µF 5% 50V
C852 1-137-374-11 FILM 0.047µF 5% 50V
C853 1-137-374-11 FILM 0.047µF 5% 50V
C854 1-126-933-11 ELECT 100µF 20% 16V
C855 1-102-973-00 CERAMIC 100pF 5% 50V
C856 1-102-973-00 CERAMIC 100pF 5% 50V
C857 1-126-933-11 ELECT 100µF 20% 16V
C858 1-104-665-11 ELECT 100µF 20% 25V
C859 1-104-665-11 ELECT 100µF 20% 25V
C860 1-126-933-11 ELECT 100µF 20% 16V
C861 1-137-374-11 FILM 0.047µF 5% 50V
C862 1-137-374-11 FILM 0.047µF 5% 50V
C863 1-137-374-11 FILM 0.047µF 5% 50V
C864 1-126-933-11 ELECT 100µF 20% 16V
C865 1-137-366-11 FILM 0.0022µF 5% 50V
C866 1-136-177-00 FILM 1µF 5% 50V
C867 1-104-664-11 ELECT 47µF 20% 25V
C868 1-164-096-11 CERAMIC 0.01µF 50V
C869 1-130-487-00 MYLAR 0.022µF 5% 50V
C870 1-164-096-11 CERAMIC 0.01µF 50V
C872 1-126-960-11 ELECT 1µF 20% 50V
C873 1-126-964-11 ELECT 10µF 20% 50V
C876 1-102-973-00 CERAMIC 100pF 5% 50V
C877 1-102-973-00 CERAMIC 100pF 5% 50V
C880 1-104-664-11 ELECT 47µF 20% 5V
C881 1-102-973-00 CERAMIC 100pF 5% 50V
C882 1-102-973-00 CERAMIC 100pF 5% 50V
C883 1-102-973-00 CERAMIC 100pF 5% 50V
C884 1-104-665-11 ELECT 100µF 20% 25V
C885 1-104-664-11 ELECT 47µF 20% 25V
E
C513 1-126-965-11 ELECT 22µF 20% 50V
C514 !1-162-116-91 CERAMIC 680pF 10% 2KV
C515 !1-125-831-91 FILM 0.033µF 3% 630V
C516 !1-117-648-11 FILM 15000pF 3% 1.2KV
C518 1-130-495-00 FILM 0.1µF 5% 50V
C519 1-106-359-00 MYLAR 0.0047µF 10% 100V
C520 1-162-116-00 CERAMIC 680pF 10% 2KV
C521 1-162-116-00 CERAMIC 680pF 10% 2KV
C523 1-115-521-11 FILM 0.82µF 5% 200V
C524 1-106-359-00 MYLAR 0.0047µF 10% 100V
C526 1-102-228-00 CERAMIC 470pF 10% 500V
C527 1-126-970-11 ELECT 330µF 20% 50V
C528 1-107-957-11 ELECT 1µF 20% 250V
C529 1-109-844-11 FILM 0.68µF 5% 250V
C530 1-107-648-91 ELECT 100µF 20% 160V
C531 1-126-971-11 ELECT 470µF 20% 50V
C532 1-126-971-11 ELECT 470µF 20% 50V
C533 1-107-655-11 ELECT 47µF 20% 250V
C535 1-106-387-00 MYLAR 0.068µF 10% 200V
C536 1-137-374-11 FILM 0.047µF 5% 50V
C537 1-126-968-11 ELECT 100µF 20% 50V
C538 1-126-968-11 ELECT 100µF 20% 50V
C539 1-162-114-00 CERAMIC 0.0047µF 2KV
C540 1-137-372-11 FILM 0.022µF 5% 50V
C541 1-137-374-11 FILM 0.047µF 5% 50V
C542 1-126-934-11 ELECT 220µF 20% 16V
C544 1-104-665-11 ELECT 100µF 20% 25V
C545 1-104-665-11 ELECT 100µF 20% 25V
C548 1-102-244-00 CERAMIC 220pF 10% 500V
C550 1-126-935-11 ELECT 470µF 20% 16V
C551 1-126-935-11 ELECT 470µF 20% 16V
C554 1-130-062-91 FILM 0.0056µF 5% 630V
C555 1-126-960-11 ELECT 1µF 20% 50V
C556 1-130-495-00 MYLAR 0.1µF 5% 50V
C701 1-126-933-11 ELECT 100µF 20% 16V
C801 1-104-665-11 ELECT 100µF 20% 25V
C802 1-104-665-11 ELECT 100µF 20% 25V
C803 1-126-934-11 ELECT 220µF 20% 16V
C804 1-126-934-11 ELECT 220µF 20% 16V
C805 1-126-934-11 ELECT 220µF 20% 16V
C806 1-126-934-11 ELECT 220µF 20% 16V
C807 1-137-374-11 FILM 0.047µF 5% 50V
C808 1-137-374-11 FILM 0.047µF 5% 50V
C809 1-137-374-11 FILM 0.047µF 5% 50V
C810 1-137-374-11 FILM 0.047µF 5% 50V
C811 1-102-074-00 CERAMIC 0.001µF 10% 50V
C812 1-136-169-00 FILM 0.22µF 5% 50V
C813 1-137-374-11 FILM 0.047µF 5% 50V
C815 1-104-665-11 ELECT 100µF 20% 25V
C816 1-130-014-00 FILM 470pF 5% 50V
C817 1-104-664-11 ELECT 47µF 20% 25V
C818 1-126-933-11 ELECT 100µF 20% 16V
C819 1-104-664-11 ELECT 47µF 20% 25V
C820 1-102-129-00 CERAMIC 0.01µF 10% 50V
C821 1-130-495-00 MYLAR 0.1µF 5% 50V
C822 1-107-648-91 ELECT 100µF 20% 160V
C823 1-104-664-11 ELECT 47µF 20% 25V
