Specifications
Others
Specifications
Optical characteristics
Projection system
3 LCD panels, 1 lens, projection
system
LCD panel VPL-ES3: 0.63-inch SVGA panel,
about 1,440,000 pixels (480,000
pixels × 3)
VPL-EX3: 0.63-inch XGA panel,
about 2,360,000 pixels (786,432
pixels × 3)
Lens 1.2 times zoom lens
f 18.8 to 22.6 mm/F1.6 to 1.94
Lamp 165 W Ultra high pressure lamp
Projected picture size
40 to 300 inches (measured
diagonally)
Light output ANSI lumen
1)
2000 lm
(When the Lamp Mode is set to
“High.”)
Throwing distance (When placed on the floor.)
40-inch: 1.2 to 1.4 m
(3.9 to 4.6 feet)
80-inch: 2.3 to 2.8 m
(7.5 to 9.2 feet)
100-inch: 2.9 to 3.6 m
(9.5 to 11.8 feet)
150-inch: 4.4 to 5.4 m
(14.4 to 17.7 feet)
200-inch: 5.9 to 7.2 m
(19.4 to 23.6 feet)
250-inch: 7.3 to 9.0 m
(24 to 29.5 feet)
300-inch: 8.8 to 10.7 m
(28.9 to 35.1 feet)
There may be a slight difference between the
actual value and the design value shown above.
1)
ANSI lumen is a measuring method of
American National Standard IT 7.228.
Electrical characteristics
Color system NTSC3.58/PAL/SECAM/
NTSC
4.43/PAL-M/PAL-N/
PAL60 system, switched
automatically/manually
(NTSC
4.43 is the color system used
when playing back a video
recorded in NTSC on a
NTSC
4.43 system VCR.)
Resolution VPL-ES3: 500 horizontal TV lines
(Video input)
800 × 600 dots (RGB input)
VPL-EX3: 750 horizontal TV
lines (Video input)
1024 × 768 dots (RGB input)
Acceptable computer signals
1)
fH: 19 to 92 kHz
fV: 48 to 92 Hz
(Maximum input signal resolution:
SXGA+ 1400 × 1050
fV: 60 Hz)
1)
Set the resolution and the frequency of the
signal of the connected computer within the
range of acceptable preset signals of the
projector.
Applicable video signals
15 k RGB 50/60 Hz, Progressive
component 50/60 Hz, DTV
(480/60i, 575/50i, 480/60p,
575/50p, 720/60p, 720/50p,
1080/60i, 1080/50i), Composite
video, Y/C video
Speaker Monaural speaker system, 40 × 20
mm (1
5
/8 ×
13
/16 inches)
Speaker output
1 W (max.)
Input/Output
Video input VIDEO: phono type
Composite video: 1 Vp-p ±2 dB
sync negative (75 ohms
terminated)
S VIDEO: Y/C mini DIN 4-pin
type
Y (luminance): 1 Vp-p ±2 dB
sync negative (75 ohms
terminated)
C (chrominance): burst
0.286 Vp-p ±2 dB (NTSC)
(75 ohms terminated),
burst 0.3 Vp-p ±2 dB (PAL)
(75 ohms terminated)
INPUTA HD D-sub15-pin (female)
Analog RGB/component:
R/R-Y: 0.7 Vp-p ±2 dB
(75 ohms terminated)
G: 0.7 Vp-p ±2 dB
(75 ohms terminated)
G with sync/Y: 1 Vp-p ±2 dB
sync negative
(75 ohms terminated)
B/B-Y: 0.7 Vp-p ±2 dB
(75 ohms terminated)
SYNC/HD: Composite sync
input: TTL level, positive/
negative
Horizontal sync input: TTL
level
Positive/negative VD:
Vertical sync input: TTL
level, positive/negative
