APPENDIX
Available DIP switch settings (Serial Interface)
The following table shows all the possible settings for the DIP switch. The
factory default settings are ON for switches 1 through 7 and OFF for switches
8 through 10.
*1: Never set switch 7 to OFF at the same time that switch 8 is set to ON.
Switch Parameter ON OFF
1
Baud Rate See table below.
2
3 Data Length 8 bits 7 bits
4 Parity Check Disabled Enabled
5 Parity Odd Even
6 Handshake DTR/DSR XON/XOFF
7
Command Emulation See table below.
8
9 Pin 6 (DSR) Reset Signal Enabled Disabled
10 Pin 25 (INIT) Reset Signal Enabled Disabled
Baud Rate Switch 1 Switch 2
1200BPS OFF OFF
2400BPS ON OFF
4800BPS OFF ON
9600BPS ON ON
Command Emulation Switch 7 Switch 8
Star mode ON ON
ESC/POS (TM-295) ON OFF
ESC/POS (TM-290) OFF OFF
Not used (*1) OFF ON
