TANDBERG Videoconferencing System
37
General use
T.120 / data
Dataport 1
COM port
T.120 and other PC applications
A PC can be connected to the system using a serial cable. This will enable interactive editing, file transfer and
application sharing between two computers.
Appropriate communication software should be used (for example: Microsoft NetMeeting, Intel ProShare Premier,
Windows HyperTerminal, Procomm Plus and so forth.)
The system has been specially designed to work with interactive programs and includes a data channel that can
send and receive data to and from the far end at speeds of up to 38,400 baud.
Streaming
To view streaming, select ‘Streaming’ from the Web-page of the codec. See separate ‘Streaming’ section in
this manual for further information.
PC SoftPresenter
A PC image can be displayed on the system using PC SoftPresenter. See ‘VNC Settings’ for further information.
LAN
Ethernet
Ethernet
Snapshots
Snapshots of current stream, selfview, and far end streams are accesible via http. See Appendix 5 for
descriptions of the possible snapshot files.
