User’s Manual
2-4
T
HE
G
RAND
T
OUR
CAUTION: Keep foreign objects out of the PC card slot. A pin or
similar object can damage the computer’s circuitry
Right side
Figure 2-3 shows the computer’s right side.
Figure 2-3 The right side of the computer
CAUTION: Keep foreign objects out of the USB connectors. A pin
or similar object can damage the computer’s circuitry.
Note: Operation of all functions of all USB devices has not been
confirmed. some functions might not execute properly.
PC Card Slot The PC card slot can accommodate one 5 mm PC card
(Type II). The slot supports 16-bit PC card and 32-bit
CardBus PC card.
Express Card The computer provides Express Card slot on its left
side, which allows you to install an additional Express
card. (Provided with some models)
Universal Serial
Bus Ports
The two Universal Serial Bus (USB) ports comply with
USB Serial 2.0 standards, which enables data transfer
speeds 40 times faster than the USB 1.1 standards. (The
ports also support USB 1.1)
Optical Media
Drive
A DVD-ROM drive, CD-RW/DVD-ROM drive,
DVD+-R/+-RW drive, DVD Super Multi drive.
Modem jack In areas where an internal modem is installed as stan-
dard equipment, there is a modem jack that lets you use
a modular cable to connect the modem directly to a tele-
phone line. The modem is not supported in some mar-
keting regions.
OPTICAL MEDIA DRIVE
USB PORTS
MODEM JACK
SECURITY LOCK SLOT
WIRLESS
COMMUNICATION SWITCH
