65
13.7.2 Monitor Parameters
Parameter
Bit Function Bank Mask Adjustment Range Multiplier
0005 word Output frequency monitor 0 FFFF 0.00 ~ 400.00Hz 0.01
0006 0
Run • stop status
0
0: Stopped
1: Running
1 Reserved
2
Forward • reverse status
0: Reverse
1: Forward
3 Accel / decel #1 / #2 selection
status
0: Accel / decel #1
1: Accel / decel #2
4 Reserved
5 Reserved
6 Reserved
7 Jog mode status 0: Normal (accel /
decel mode)
1: Jog mode
8 Feedback enable status 0: Feedback invalid
1: Feedback valid
9 Compulsory DC injection
braking mode
0: DC injection braking
inactive
1: DC injection braking
active
A Fundamental parameter
switching
0: V/F #1
1: V/F #2
B Coast stop command status 0: Normal
1: Coast to stop
C Emergency off command 0: Normal
1: Emergency off
D Reserved
E
Reserved
F Reserved
0007 word Output current monitor 0 00FF 0 ~ 255% 1
0008 word Output voltage monitor (Note
1)
0 FFFF 0 ~ 232% 0.1
0009 word IV terminal analog input value 0 FFFF 0000 ~ FFFF (0% ~
100%)
1
000A word RX terminal analog input
value
0 FFFF
0000 ~ 7FFF (-100% ~
0%), 7FFF ~ FFFF
(0% ~ 100%)
1
000B word Frequency command monitor 0 FFFF
0000 ∼ 9C40
(0.00 ∼ 400.00 Hz)
0.01
000C word Input voltage monitor (Note 1) 0 FFFF 0 ~ 255% 0.1
000D word Input terminal status monitor 0 FFFF Refer to Table 5 (page
67)
000E low
byte
Output terminal status
monitor
0 00FF Refer to Table 6 (page
67)
high
byte
Inverter Status 2 FF00
000F word Inverter Status 1 0 FFFF Refer to Table 7 (page
68)
0010 word Present trip 0 00FF
0011 high
byte
4th Past trip (most recent) 0 7F00
low
byte
3rd past trip 007F Refer to section
13.7.16 for fault codes
