Configuring the port mirroring by assigning a source port from which
to copy all packets and a sniffer port where those packets will be sent.
The selection of the sniffer mode is as follow:
TX (transmit) mode: this mode will duplicate the data transmit from
the source port and forward to the sniffer port.
RX (receive) mode: this mode will duplicate the data that send to the
source and forward to the sniffer port.
Both (transmit and receive) mode: this mode will duplicate both the
data transmit from and data that send to the source port, then it will
forward to the sniffer port.
Figure 22.
Device Status
Click on the “Status” to present the device status on this screen, it will
show the System Status, Port Status, VLAN Status, Trunk Status and
Mirror Status..
Press “Refresh” when you need to renew the posted information.
Statistic
The Statistic Menu screen will show the status of each port packet
count.
