96 Operating Manual for XDC Series Power Supply
Editing
Trigger
Source of a
Sequence
When steps are programmed to advance step by trigger, this option allows you to edit
the source of those trigger events.
To edit the sequence’s trigger source:Using Auto Sequencing
Step # Do This You Will See
1 ERROR MSGS
2
6 times or .
AUTO SEQ PGM
3 Sequence 1
4
or . Use the scroll
keys to select a sequence to work
with.
Sequence #
5
Edit Sequence
6
or . Use the scroll
keys to select the Trig Source
option.
Trig Source
7 Trig From Man
8
or . Use the scroll
keys to select the trigger source:
• Man is triggered by pressing the
trigger key.
• Ext is triggered by the rear external
trigger line.
• Imm is triggered by receiving an
INIT:IMM command
• Bus is triggered by a GPIB GET
command or a *TRG command.
Trig from ###
9 Edit Sequence
10
The sequence’s trigger source has
now been changed. Select another
sequence to work with or escape by
pressing
MENU
MENU
ENTER
ENTER
ENTER
ENTER
EXIT
