Connector Locations 5-8
4059-XXX
J15 Integrated Paper
Tray
1+5Vdc
2PSIZE2
3 Ground
4PSIZE1
5+24Vdc
6 Ground
7POUT
8+5Vdc
9 Paper Low
10 +5 V dc
J16 Staging Motor x (Not used)
J17 MPT Pick 1 MPT Pick
2+24Vdc
J18 Auto Compensator 1 +24 V dc
2N/A
3 Ground
4 Ground
5N/A
6+5Vdc
J19 MPT Paper Out 1 Ground
2POSENSE
3+5Vdc
J20 Interconnect Board N/A N/A
J21 Smart Cartridge
(Model 3455 only)
1Scart
2 Scart Ground
Connector Pin No. Signal
