Screw types for rack installation
The following screws are used in the mounting process for the Acer
Altos G510 and other rack-mount components.
Screw type Figure Usage
1 #8-32 x 0.25 inch Securing the inner mounting
rails to the server
2 Hex head
#6-32 0.25 inch
Attaching the side handles to
the server
3M4 x L8
M4 nut
Securing the mounting
brackets to the inner sliding
piece
4 M6 x L10
Cage nut
Securing the cable carrier
and the mounting rails to the
rack
Supports the M6 metal
screws for securing server
components to the rack
