Chapter 3. Operation
30 NxT1 HSSI/V.35 Module User Manual 61200771L1-1
installing modules by simply specifying the module that you want to install
in each slot.
M
ENU Displays additional status and configuration menus for the selected
module. (To access the submenus for this item, use the arrow keys to
scroll to the
M
ENU
column for the module you want to edit, and press
Enter
.) For detailed information on each submenu item, see the section
Modules/Menu on page 31.
A
LARM
Read security: 5
Displays an alarm condition on the NxT1 HSSI/V.35 Module. Press
Enter
in
this field to activate the menu.
T
EST
Read security: 5
Displays test name if the NxT1 HSSI/V.35 Module is executing a test. Press
Enter
in this field to activate the menu.
S
TATE Displays module status as either
O
NLINE
of
O
FFLINE
. Even though a module
is physically installed, it must be marked as online for it to be considered an
available resource. This field allows an installed module to be marked as of-
fline, which may be useful in system troubleshooting. If you choose
O
FFLINE
,
the module will not be in alarm condition, but will display
O
FFLINE
.
S
TATUS This read-only field provides status information on the NxT1 HSSI/V.35
Module. The following messages may display:
O
NLINE
The module is enabled, and is responding to the system controller’s status
polls. This is the normal response of the system.
N
O
R
ESPONSE
The module is enabled, but is not responding to the system controller’s status
polls. This response indicates either a problem in the system or that the mod-
ule is not installed.
T
YPE
automatically displays the name of an installed module. If you want to change this field to
a different type of module, you must set T
YPE
to E
MPTY
before selecting the other module.
Once a module is installed, S
TATE
must be set to O
NLINE
in order for the ATLAS 800 Series unit
to use the module for any data bandwidth.
