Tab. 5b Thyro-S Status
6.4 Input and output data Thyro-A
Tab. 6 Cyclic input and output data with Thyro-A 1A...H1
Tab. 7 Cyclic input and output data with Thyro-A 1A...HRL1
Description Bit LEDs Relay
Pulse inhib active Bit 0 none open
(bridge X2.1-X2.2 open) Bit 0 none open
Mains frequency is 60Hz Bit 2 none open
Relay status Bit 8 none open
(0=relay off / 1=relay on) Bit 8 none open
Device switched off Bit 9 -- closed
Wrong device Bit 10 -- ----
Bus module active
(0=no bus module / 1=bus module active)
Bit 11 none ----
Thyristor short-circuit Bit 14 Test LED and Load Fault LED
flashing alternately slowly
----
Offset Input data, actual values Data type Size Unit
0 Load voltage L1 float 4 [V]
4 Mains voltage L1 integer 2 [V]
6 Switch-on time TS integer 2 [period]
8 Switch-on angle alpha integer 2 [0.01 °el]
10 Total setpoint integer 2 4096=100%
12 Fault (see table 14b) integer 2 -
14 Status (see table 14b) integer 2 -
Offset Output data, setpoint Data type Size Unit
0 Master setpoint integer 2 4096=100%
Offset Input data, actual values Data type Size Unit
0 Load voltage L1 float 4 [V]
4 Load current L1 float 4 [A]
8 Mains voltage L1 integer 2 [V]
10 Switch-on time TS integer 2 [period]
12 Switch-on angle alpha integer 2 [0.01 °el]
14 Total setpoint integer 2 4096=100%
16 Fault (see table 14b) integer 2 -
18 Status (see table 14b) integer 2 -
Offset Output data, setpoint Data type Size Unit
0 Master setpoint integer 2 4096=100%
