6.8 Input and output data Thyro-Measurement Unit
Tab. 25 Cyclic input and output data TMU mode
Offset Input data, actual values Data type Size Unit
0 AC input 1 float 4 [A],[V]
4 AC input 2 float 4 [A],[V]
8 AC input 3 float 4 [A],[V]
12 Power float 4 [W]
16 Energy float 4 [kWh]
20 DC input 1 integer 2 4096=100%
22 DC input 2 integer 2 4096=100%
24 DC input 3 integer 2 4096=100%
26 Mains voltage integer 2 [V]
28 Period duration integer 2 [μs]
30 Temperature integer 2 [°C]
32 Fault (see table 25b) integer 2 -
34 Status (see table 25b) integer 2 -
Tab. 25b Status TPM, TSC, TIO, TMU
Tab. 25b Fault TPM, TSC, TIO, TMU
Description Bit Fault LED, fault output*
Frequency measurement outside of 47Hz to 63Hz Bit 0 on
SYNC error, no cero crossing within the gate Bit 1 on
Temperature max. limit has been exceeded Bit 2 on
Temperature min. limit has been exceeded Bit 3 on
One or more parameters outside the limits Bit 4 on
Mains voltage lower than lower voltage limit Bit 5 on
Description Bit Alarm LED, alarm output*
Mains frequency is 60Hz Bit 2 off
Transformer 1 fallen below min. limit Bit 3 on
Transformer 1 exceeded max. limit Bit 4 on
Transformer 2 fallen below min. limit Bit 5 on
Transformer 2 exceeded max. limit Bit 6 on
Transformer 3 fallen below min. limit Bit 7 on
Transformer 3 exceeded max. limit Bit 8 on
Device switched off Bit 9 --
Wrong device Bit 10 --
Bus module active (0=no bus module / 1=bus module
active)
Bit 11 off
* Default setting can be parameterized.
