Document No. DER-S0008A 11 Version 1.0 ©2008 DMC Co., Ltd.
TSC-30/IC Product S
p
ecification
“L” output peak current *2
(Pin number 27-50)
I
OH (peak) 10 mA
“L” output peak current *2
(Pin number 16-19)
I
OH (peak) 20 mA
“L” output peak current *2
(Pin number 1-6, 51-64)
I
OH (peak) 10 mA
“H” output average current *3
(Pin number 16-19, 27-50)
I
OH (avg) -5 mA
“H” output average current *3
(Pin number 1-6, 51-64)
I
OH (avg) -5 mA
“L” output average current *3
(Pin number 27-50)
I
OL (avg) 5 mA
“L” output average current *3
(Pin number 16-19)
I
OL (avg) 10 mA
“L” output average current *3
(Pin number 1-6, 51-64)
I
OL (avg) 5 mA
Vibration frequency *4
X
IN 6.0 MHz
In USB mode
Tolerance:±0.25%
*1 The total peak output current is the absolute value of the peak currents flowing through all the
applicable ports. The total average output current is the average value of the absolute value of the
currents measured over 100ms flowing through all the applicable ports.
*2 The peak output current is the absolute value of the peak current flowing in each port.
*3 The average output current is the average value of the absolute value of the currents measured over
100ms.
*4 The duty of oscillation frequency is 50%.
