Document No. DER-S0008A 14 Version 1.0 ©2008 DMC Co., Ltd.
TSC-30/IC Product S
p
ecification
5-4. DC standards
(Vcc=3.00 to 5.25V, Vss=0V, Ta=-20 to 85˚C, unless otherwise noted)
Rating
Item Symbol Condition
Minimum Standard Maximum
Unit
IOH = -10mA
VCC = 4.0 to 5.25V
Vcc-2.0
“H” Output voltage
(Pin number 16-19, 27-50)
V
OH
IOH = -1.0mA
VCC-1.0
V
IOH = -10mA
VCC = 4.0 to 5.25V
Vcc-2.0
“H” Output voltage
(Pin number 1-6, 51-64)
V
OH
IOH = -1mA
Vcc-1.0
“H” Output voltage
(Pin number. 25 (D+), 26 (D-))
V
OH
Pull-down with 0V via a
resistor of 15kΩ±5%
2.8 3.6 V
IOL = 10mA
V
CC = 4.0 to 5.25V
2.0
“L” Output voltage
(Pin number 27-50)
V
OL
IOL = 1mA
1.0
V
IOL = 20mA
V
CC = 4.0 to 5.25V
2.0
“L” Output voltage
(Pin number 16-19)
V
OL
IOL = 1mA
1.0
V
“L” Output voltage
(Pin number. 25 (D+), 26 (D-))
V
OL
Pull-up with 3.6V via a
resistor of 15kΩ±5%
0.3
V
IOL = 10mA
V
CC = 4.0 to 5.25V
2.0
“L” Output voltage
(Pin number 1-6, 51-64)
V
OL
I
OL = 1mA
1.0
V
hysteresis
(Pin number 35-37)
V
T+ - VT- 0.6 V
hysteresis
(Pin number 1-6, 51-64)
V
T+ - VT- 0.6 V
hysteresis
(Pin number 25(D+), 26(D-))
V
T+ - VT- 0.25 V
hysteresis
(Pin number 8)
V
T+ - VT- 0.5 V
“H” Input current
(Pin number 16-19, 27-50)
I
IH VI = VCC 5.0 μA
“H” Input current
(Pin number 1-6, 51-64)
I
IH VI = VCC 5.0 μA
“H” Input current
(Pin number 7, 8)
I
IH VI = VCC 5.0 μA
“H” Input current
(Pin number 12)
I
IH VI = VCC 4.0 μA
“L” Input current
(Pin number 16-19, 27-50)
I
IL VI = VSS -5.0 μA
Input “L” current
(Pin number 1-6, 51-64)
I
IL VI = VSS -5.0 μA
Input “L” current
(Pin number 7, 8, 15)
I
IL VI = VSS -5.0 μA
Input “L” current
(Pin number 12)
I
IL VI = VSS -4.0 μA
