To Install the HP 16500H Hardware
If you need instructions for removing and replacing parts of the HP 16500B,
refer to the
HP 16500B Logic Analysis System Service Guide
.
WARNING
SHOCK HAZARD
Disconnect the power from the mainframe before
performing the following procedures. After disconnecting the power, wait at
least six minutes for the capacitors on the power supply board and the CRT
driver board to discharge before servicing the instrument. Failure to do so
could result in electrical shock. Hazardous voltages exist on the power
supply, the CRT, and the CRT driver board of the HP 16500B mainframe. As
long as the AC LED on the power supply has any illumination, a significant
charge remains on the capacitors.
CAUTION
Use grounded wriststraps and mats when performing any service to this
module or to the HP 16500B Logic Analysis System. Electrostatic discharge
can damage electronic components.
For correct orientation of the cables, match the slots on the cable connectors
and on the board connectors.
1
Remove power from the HP 16500B mainframe, then remove the
measurement modules, the four rear feet, and the top and bottom
covers of the mainframe.
2
Remove the sheetmetal plate on the rear of the mainframe covering
the slot where the interface module will be installed.
With the interface module installed, you will not use the plate. Save the plate
to use in case the interface module is removed.
Installing the Interface Module
To Install the HP 16500H Hardware
2–2
