Removing and Replacing the HP 16500H Interface
Module
1
If the HP 16500B Logic Analysis System is connected and mounted to
a LAN, then unmount the HP 16500B file system.
Unmounting from a LAN
You must unmount the HP 16500B before power is removed from it. Then, you
can mount the HP 16500B 15 seconds after the System Configuration menu is
displayed when powering up the instrument. You can write a network script
that executes an unmount and mount procedure.
2
If the HP 16500B Logic Analysis System is being used in the HP
16505A prototype analyzer environment:
a
Save all work and close all windows.
b
Open the Session Manager window, then select Power Down.
c
Remove power from the HP 16505A Prototype Analyzer, then remove
power from the HP 16500B mainframe.
d
Disconnect the HP 16505A interface cable, HP 16501A interface cable,
and LAN cable from the interface board.
3
Turn off the power switch located on the front panel of the
HP 16500B mainframe and the standby switch located on the rear
panel. Then, unplug the power cord from the mainframe.
Refer to the HP 16500B Service Guide if you need instructions for removing
and replacing parts of the HP 16500B.
3
Remove the two rear feet on the top and the top cover of the
HP 16500B mainframe.
4
On the interface module, disconnect the cable from the CPU board.
Servicing the Interface Module
Removing and Replacing the HP 16500H Interface Module
3-10
