xii
ASUS Q-Fan
ASUS CrashFree BIOS 2
ASUS MyLogo 2
1 x Parallel port
1 x Serial port
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x LAN (RJ45) port
1 x S/PDIF Out port
4 x USB 2.0 ports
6-channel audio ports
1 x WiFi-g™ antenna port
(Wireless Edition only)
1 x Wireless LAN LED
(Wireless Edition only)
1 x IDE connector
1 x Floppy disk drive connector
4 x SATA connectors
1 x CPU fan connector
1 x Chassis fan connector
1 x Power fan connector
1 x Chassis intrusion connector
1 x CD audio-in connector
1 x GAME/MIDI connector
1 x S/PDIF Out port
1 x Front panel audio connector
1 x 24-pin ATX power connector
1 x 4-pin ATX 12 V connector
2 x USB connectors support 4 additional USB ports
4 Mb Flash ROM, AMI BIOS, PnP, DMI2.0, WfM2.O,
SM BIOS2.3, ASUS EZ Flash, ASUS CrashFree BIOS2,
ASUS MyLogo 2
WOL by PME, WOR by PME, Chassis Intrusion
Drivers
ASUS PC Probe II
ASUS LiveUpdate
Anti-virus Software
1 x UltraDMA 133/100/66 cable
1 x USB/GAME cable
1 x FDD cable
2 x SATA cables
2 x SATA power cables
1 x I/O shield
1 x User’s manual
ATX 12 in x 7.5 in (30.5 cm x 19 cm)
P5LD2 SE specications summary
Other ASUS
Special Features
Back Panel I/O
Ports
Internal I/O
Connectors
BIOS Feature
Manageability
Support CD
Accessory
Form Factor
*Specications are subject to change without notice.
