10 AXIS 5500 / AXIS 5550 User’s Manual
Physical Description
AXIS 5500
AXIS 5550
Network Connector Axis Network Print Servers are designed for 10 Mbps or 100 Mbps
Ethernet networks and connect to the network via a twisted pair RJ45
category 5 cable (10baseT and 100baseTX) or better.
Printer Ports
AXIS 5500 • One Low- and Full-Speed USB 1.1 port, and works with USB v 2.0
(Low-Speed and Full-Speed).
The USB cable shipped with the product supports Low-Speed and Full-
Speed. IMPORTANT! Hi-Speed is not supported.
AXIS 5550 • One Low- and Full-Speed USB 1.1 port, and works with USB v 2.0
(Low-Speed and Full-Speed).
The USB cable shipped with the product supports Low-Speed and Full-
Speed. IMPORTANT! Hi-Speed is not supported.
• One high-speed IEEE 1284 compatible parallel port.
Power Adapter
connector
Ethernet
connector
Network
indicator
Power
indicator
USB printer port (USB1)
Test button
Ethernet connector
Power Adapter
connector
Test button
Power
Indicator
Network
Indicator
Parallel printer port (LPT1)
USB printer port (USB1)
