RS-422/485 SERIAL INTERFACE PLUS, 4-PORT
Table A-2. DB37 Pin Assignments.
Port # 1 2 3 4
GND 33 14 24 5
TX- 35 12 26 3
RTS- 17 30 8 21
TX+ 34 13 25 4
RX- 36 11 27 2
CTS- 16 31 7 22
RTS+ 18 29 9 20
RX+ 37 10 28 1
CTS+ 15 32 6 23
Black Box IC183C Network Card User Manual
