CHAPTER 4: Technical Description
Table 4-6 (continued). Cable with two female ends (side A, side B).
DB37 DB37
Labeled Jumper Labeled Jumper
Side A Function Pin Side B Pin Common
33 Relay 27A PORT 4-A3 33 Relay 27B PORT 4-B3
34 Relay 29A PORT 4-A5 34 Relay 29B PORT 4-B5
35 Relay 31A PORT 4-A7 35 Relay 31B PORT 4-B7
36 Ground N/A 36 Ground N/A
37 Ground N/A 37 Ground N/A
