LOCATION AND CONNECTIONS
Connections
Connecting the Machine
Connect the handset, power cord and telephone line.
1
Connect the handset.
Connect the curled handset cord to the bottom of the handset and to the left side of the
machine.
2
Connect the power cord.
3
Connect the telephone line.
Connect one end of the telephone line cord to the jack labeled
LINE
on the left side
of the machine. Connect the other end to a modular wall jack.
WARNING
This machine must be grounded using a three-prong plug.
Since the machine is grounded through the power outlet, you can protect yourself from
potentially hazardous electrical conditions on the telephone line by keeping the power
to your machine on when you connect it to a telephone line. When you want to move
your machine, protect yourself by disconnecting the telephone line first, and then the
power cord.
Lightning and power surges can damage this product! We recommend that you use a
quality surge protection device on the AC power line as well as on the telephone line,
or unplug the lines during a lightning storm.
