3-16
Cisco TelePresence System
OL-16441-01
Chapter 3 Options for the Cisco TelePresence System 3000
Cisco TelePresence Presentation Codec
Step 17 Route the power cables for the presentation codec.
Figure 3-14 Presentation Codec Cable Routing
Step 18 Power on the CTS-3000 by turning the power switches to the On position for the two left PDUs, single
right PDU, and the PDU on the central display if it is present.
Note Write down the IP address that displays on the bottom right corner of the display screens. This is the
address of the primary codec unit.
Step 19 In the browser on the computer, type in the IP address of the primary codec unit.
Step 20 Enter the required information at the login screen. The Cisco TelePresence Administrator window
appears.
Power
204191
