Client Quality of Service
Class Map
Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 127
7
0 to 1023—Well-Known Ports
1024 to 49151—Registered Ports
49152 to 65535—Dynamic and/or Private Ports
• Destination Port—Includes a destination port in the match condition for the
rule. The destination port is identified in the datagram header.
If you select this field, choose the port name or enter the port number.
- Select From List—Matches the destination port in the datagram header
with the selected keyword: ftp, ftpdata, http, smtp, snmp, telnet, tftp,
www.
Each of these keywords translates into its equivalent port number.
- Match to Port—Matches the destination port in the datagram header
with an IANA port number that you specify. The port range is from 0 to
65535 and includes three different types of ports:
0 to 1023—Well Known Ports
1024 to 49151—Registered Ports
49152 to 65535—Dynamic and/or Private Ports
• EtherType—Compares the match criteria against the value in the header of
an Ethernet frame.
Select an EtherType keyword or enter an EtherType value to specify the
match criteria.
- Select from List—Matches the Ethertype in the datagram header with
the selected protocol types: appletalk, arp, ipv4, ipv6, ipx, netbios,
pppoe.
- Match to Value—Matches the Ethertype in the datagram header with a
custom protocol identifier that you specify. The value can be a four-digit
hexadecimal number in the range of 0600 to FFFF.
• Class of Service—A class of service 802.1p user priority value to be
matched for the packets. The valid range is from 0 to 7.
• Source MAC Address—A source MAC address to compare against an
Ethernet frame.
• Source MAC Mask—The source MAC address mask specifying which bits
in the destination MAC to compare against an Ethernet frame.
