Status and Statistics
System Summary
Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 16
2
• Serial Number—The serial number of the Cisco WAP device.
• Base MAC Address—The WAP MAC address.
• Firmware Version—The firmware version number of the active image.
• Firmware MD5 Checksum—The checksum for the active image.
• Host Name—A name assigned to the device.
• System Uptime—The time that has elapsed since the last reboot.
• System Time—The current system time.
• Power Source—The system may be powered by a power adapter, or may
be receiving power-over-Ethernet from PoE power-sourcing equipment
(PSE).
The TCP/UDP Service table shows basic information about protocols and
services operating on the WAP.
• Service—The name of the service, if available.
• Protocol—The underlying transport protocol that the service uses (TCP or
UDP).
• Local IP Address—The IP address, if any, of a remote device that is
connected to this service on the WAP device. All indicates that any IP
address on the device can use this service.
• Local Port—The port number for the service.
• Remote IP Address—The IP address of a remote host, if any, that is using
this service. All indicates that the service is available to all remote hosts that
access the system.
• Remote Port—The port number of any remote device communicating with
this service.
• Connection State—The state of the service. For UDP, only connections in
the Active state appear in the table. In the Active state, a connection is
established between the WAP device and a client or server. The TCP states
are:
- Listening—The service is listening for connection requests.
- Active—A connection session is established and packets are being
transmitted and received.
