Item Component Spare part number
For use on computer models equipped with an AMD E1-1200 processor (1.40-GHz,
1066-MHz, 18 W, dual core) and a UMA graphics subsystem memory
688303-501
(10) Fan/heat sink assembly (includes replacement thermal material) 688306-001
(11) Power connector cable (includes bracket) 686258-001
(12) Base enclosure (includes battery cover lock latch, battery cover release latch, power
connector barrel, and RJ45 cover):
708523-001
Rubber Kit (not illustrated, includes front and rear rubber feet, display bezel rubber
bumpers, and display bezel rubber screw covers)
686276-001
(13) Battery:
6-cell, 55-Wh, 2.55-Ah, Li-ion battery 593554-001
6-cell, 47-Wh, 2.20-Ah, Li-ion battery 593553-001
(14) DVD±RW Double-Layer with SuperMulti Drive (includes optical drive bezel
and optical drive bracket)
686268-001
(15) RTC battery 686274-001
(16) Hard drive (does not include hard drive bracket, hard drive connector cable, or screws):
750-GB, 5400-rpm, 9.5-mm 634250-001
640-GB, 5400-rpm, 9.5-mm 669300-001
500-GB, 5400-rpm, 9.5-mm 669299-001
500-GB, 5400-rpm, 7.0-mm 683802-001
320-GB, 5400-rpm, 9.5-mm 622643-001
320-GB, 5400-rpm, 7.0-mm 645193-001
Hard Drive Hardware Kit (not illustrated, includes hard drive bracket, hard drive
connector cable, and screws)
686261-001
(17) Memory module (PC3, 12800, 1600-MHz):
4-GB memory module 652972-001
2-GB memory module 641369-001
(18) WLAN module:
Atheros AR9565 802.11b/g/n 1×1 WiFi + BT4.0 Combo Adapter 690019-001
Atheros HB125 802.11b/g/n 1×1 WLAN module 675794-001
Atheros 9485GN 802.11b/g/n 1×1 WiFi and 3012 Bluetooth 4.0 Combo Adapter 655795-001
Broadcom 4313GN 802.11b/g/n 1×1 WiFi and 20702 Bluetooth 4.0
Combo Adapter
657325-001
Ralink RT5390F 802.11b/g/n 1×1 WLAN module 670691-001
Ralink RT5390R 802.11bg/n 1×1 WiFi Adapter 691415-001
Ralink RT3290LE 802.11b/g/n 1×1 WiFi and Bluetooth 4.0 Combo Adapter 690020-001
Computer major components
19
