10.
If it is necessary to replace the webcam/microphone module, gently detach the webcam/
microphone module from the display enclosure. (The webcam/microphone module is attached to
the display enclosure with double-sided tape.)
CAUTION: Due to the thin profile of the webcam/microphone module, it is easily damaged.
Take extra precaution to ensure the webcam/microphone module is not damaged when removing
and replacing the module.
The webcam/microphone module is available using spare part numbers 703461-001
(HD webcam/microphone module) and 686285-001 (non-HD webcam/microphone module).
NOTE: Depending on computer model, some computer models may be equipped one or two
sets of wireless antenna cables and transceivers.
11. If it is necessary to replace the wireless antenna cables and transceivers:
a. Detach the wireless antenna transceivers (1) from the display enclosure. (The wireless
antenna transceivers are attached to the display enclosure with double-sided tape.)
b.
Release the wireless antenna cables from the clips and routing channels along the left, right,
and bottom edges of the display enclosure (2).
Component replacement procedures
75
