Document History Page
Document Title: SL811HS Embedded USB Host/Slave Controller
Document Number: 38-08008
REV. ECN NO. Issue Date
Orig. of
Change
Description of Change
** 110850 12/14/01 BHA Converted to Cypress format from ScanLogic
*A 112687 03/22/02 MUL 1) Changed power supply voltage to 4.0V in section 7.1
2) Changed value of twdsu in section 7.6.2
3) Changed max. power supply voltage to 3.45 V in section 7.2
4) Changed accuracy of adjustment in section 7.2
5) Changed bits 0 and 1 to reserved in section 5.3.8
6) Changed bit 2 to reserved in section 5.3.5 and 5.3.7
7) Changed bit 2 to reserved in section 5.3.1
8) Changed definition of bit 6 in section 5.3.5 & 5.3.7
9) Added section 5.1, Register Values on Power Up and Reset
10) Changed bit description notes in section 5.3.7
11) Changed note about series termination resistors in section 7.5
12) Changed example in section 5.3.9
13) Changed J-K Programming States table in section 5.3.2
14) Added and removed comments for low-power modes in section 5.3.4
15) Removed sections specific to slave operation and SL11H
16) Removed duplicate tables
17) General formatting changes to section headings
18) Fixed all part number references
19) Added comments to section 7.5 and new definitions to section 2.0
*B 381894 See ECN VCS Went from single column to 2-column format. Combined information from
SL811HS (38-08008) and SL811S/T (83-08009)
*C 464641 See ECN ARI Added lead free part numbers to new section Ordering Information and
corrected references made to these parts. Corrected grammar. Added
compliance statement in section USB Host Transceiver Characteristics.
*D 749518 See ECN ARI Implemented the new template. Changed Figure 4. Labels on pins 2 and 3
were swapped; this has been corrected.
Combined the 48-pin TQFP AXC Pin Assignment and Definition table with
the 28-pin PLCC Pin Assignment and Definition table. Removed all instances
of SL811HST-AC. Corrected the variables. Removed references to the
obsolete SL11H.
