Command ASCII Command
(Host to Device)
Response
(Device to Host)
Additional Description
Picture Adjustment (Analog Only)
Pixel phase
Set a pixel phase value
E1*X2@PHAS} PhasX2@] Adjust the pixel phase to X2@.
Increment value
E1+PHAS} PhasX2@]
Increase the pixel phase.
Decrement value
E1-PHAS} PhasX2@]
Decrease the pixel phase
View pixel phase value
E1PHAS} X2@]
Show the pixel phase value
Total pixels
Set a value
E1*X2#TPIX} TpixX2#]
Set the total pixels.
Increment value
E1+TPIX} TpixX2#]
Increase the total pixels.
Decrement value
E1-TPIX} TpixX2#]
Decrease the total pixels.
View total pixel value
E1TPIX} X2#]
Show the total pixels.
Horizontal start
Set horizontal start value
E1*X2$HSRT} HsrtX2$]
Set horizontal location of first
active pixel in active window.
Increment value
E1+HSRT} HsrtX2$]
Move the image to the right.
Decrement value
E1-HSRT} HsrtX2$]
Move the image to the left.
View horizontal start value
E1HSRT} X2$]
Show horizontal location of the
first active pixel in active window.
EDID
NOTE: Digital EDID can be assigned only to a digital input. Analog EDID can be assigned only to an analog
input.
Input EDID (VGA and HDMI)
Assign factory EDID
EAX1!*X2^EDID} EdidAX1!*X2^]
Set the EDID resolution and
refresh for input X1!.
View assigned EDID
EAX1!EDID} X2^]
View EDID resolution and refresh
for input X1!.
View EDID native resolution
ENX1!EDID} X@]
View current EDID in Hex
ERX1!EDID} X#]
Export EDID selection
EEX2^EDID} X$]
Export EDID in binary format.
Import EDID to store
location
EIX1$EDID}X$ EdidIX1$]
Import EDID in binary format to
user stored EDID slot X1$.
NOTE: X@ = Native resolution and refresh rate
X# = EDID record (Hex) 128 or 256 bytes
X$ = EDID record (binary) 128 or 256 bytes
X1! = Input selection 1 = VGA (input 1)
2 = HDMI (input 2)
3 = HDMI (input 3)
X1$ = User assigned EDID 55 = VGA (input 1)
56 = HDMI (input 2)
57 = HDMI (input 3)
X2@ = Pixel phase 0 to 63 (32 = default)
X2# = Total pixels ±255 of the default value (depends on the input rate)
X2$ = Horizontal start 0 to 255 (128 = default)
X2^ = EDID output resolution See the tables on page 13.
FOX T USW 103 Universal Switcher • Remote Control 16
