Command ASCII Command
(Host to Device)
Response
(Device to Host)
Additional Description
Device name
NOTE: No blank or space characters are permitted. The first character must be a letter. The last character
cannot be a minus or hyphen.
Set unit name
EX1^CN} Ipn
•
X1^]
Set device name.
Set unit name to factory
default
E
•
CN} Ipn
•
X1&]
Set device to default.
View unit name
ECN} X1^]
View device name.
Information requests
Query general information
I
1Lnk
X%
•
2LnkX%
•
VidX%
•
AudX%
•
X1)
•
TX]
Query firmware version
Q
x.xx
]
Query firmware build
*Q
x.xx.xxxx
]
Query part number
N
60-1229-nn
]
Query all firmware version
0Q
x.xx-x.xx
]
Query updated FPGA version
35Q
x.xx
]
Status request
View fiber link 1 status
1S
X%]
View fiber link 2 status
2S
X%]
View input video status
3S
X%X%X%]
View input audio status
4S
X%]
Request all signal status
5S
SigI
X%X%X%
•
SigO-
•
2HdcpIX%
•
3HdcpIX%
•
HdcpO-]
Request HDMI signal status
6S
SigI
X%X%
•
SigO-]
Request HDCP status
7S
2HdcpI
X%
•
3HdcpIX%
•
HdcpO-]
NOTE: X% = On or off 0 = off or not detected
1 = on or detected
X1) = SFP module type SM = singlemode
MM = multimode
X1! = Input selection 1 = VGA (input 1)
2 = HDMI (input 2)
3 = HDMI (input 3)
X1^ = Unit name text string up to 24 characters (A-Z, 0-9, -). No blank
or space characters are permitted. The first character
must be a letter. The last character cannot be a hyphen.
X1& = Extron device name FOX-T-USW-103
FOX T USW 103 Universal Switcher • Remote Control 18
