Refer also to the VersaTools
®
MTP Series User’s Manual at www.extron.com.
Signal Jumpers for Generational Compatibility
The latest generation MTP transmitters convert stereo audio to
mono before outputting it to the receiver. Remote powering
of either the transmitter or receiver has also been eliminated.
While the default setup of a new generation (mono audio) MTP
transmitter/receiver is not compatible with older generation
(stereo audio) units, internal jumpers provide backward
compatibility and also allow new generation units to utilize
the two features (stereo audio and remote powering) when
necessary.
Shift the new transmitter and/or receiver jumper if:
The installation mixes a transmitter/receiver pair with •
stereo and mono audio (old and new generation).
Stereo audio is required.•
Remote power is needed.•
The table below identies the generation of transmitter and/or
receiver. If any of the above scenarios are true, consult the
VersaTools MTP Series User's Manual or www.extron.com for
instructions on properly setting the jumper.
N
Only new generation units have jumpers.
Transmitter Old generation
(stereo audio)
New generation
(mono audio)
MTP T SV 60‑540‑02 60‑540‑42
MTP T SV A 60‑540‑22 60‑540‑52
MTP T SV A RCA 60‑541‑32 60‑540‑62
MTP T SV A AAP 70‑362‑02, ‑03 70‑362‑22, ‑23
MTP T CV 60‑540‑01 60‑540‑41
MTP T AV 60‑540‑21 60‑540‑51
MTP T AV RCA 60‑540‑31 60‑540‑61
MTP T AV AAP 70‑361‑02, ‑03 70‑361‑22, ‑23
Receiver Old generation
(stereo audio)
New generation
(mono audio)
MTP R SV 60‑541‑02 60‑541‑42
MTP R SV A 60‑541‑22 60‑541‑52
MTP R SV A RCA 60‑541‑32 60‑541‑62
MTP R CV 60‑541‑01 60‑541‑41
MTP R AV 60‑541‑21 60‑541‑51
MTP R AV RCA 60‑541‑31 60‑541‑61
VersaTools
®
MTP Series • Installation
1-3
