ETERNUS DX Disk storage systems User’s Guide -Server Connection- (iSCSI) for VMware® ESX
13
Copyright 2012 FUJITSU LIMITED P3AM-3412-11ENZ0
Chapter 3 Notes
This chapter describes notes when the ETERNUS DX Disk storage systems are connected to
the server via iSCSI interface.
3.1 Connection Notes
3.1.1 For VMware vSphere
Dedicated IP addresses must be allocated to the iSCSI LAN. An IP address must be allocated to
each VMkernel that corresponds to an iSCSI Initiator, and a LAN card and VMkernel must be
connected via a virtual switch. For example, a total of four IP addresses are required by the fol-
lowing iSCSI connection setup.
Example connection configuration
IP address
for iSCSI port (3)
IP address
for iSCSI port (4)
VMware ESX server
VMkernel (iSCSI Software Initiator)
IP address (1)
VMkernel (iSCSI Software Initiator)
IP address (2)
LAN card
LAN card
LAN switch
LAN switch
ETERNUS DX Disk storage system
