Chapter 6 Setting Up the VMware ESX Server
6.2 Setting Up for VMware Infrastructure 3
ETERNUS DX Disk storage systems User’s Guide -Server Connection- (iSCSI) for VMware® ESX
35
Copyright 2012 FUJITSU LIMITED P3AM-3412-11ENZ0
9 Confirm that the IP address for the iSCSI port of the ETERNUS DX Disk storage
system is displayed as follows and click [Close].
10 If the connected ETERNUS DX Disk storage system uses multiple iSCSI ports,
repeat the IP address addition process for each iSCSI port. (Repeat Step 7
through Step 9
.)
End of procedure
6.2.5 Setting the CHAP Authentication
For VMware ESX connections, the ETERNUS DX Disk storage system uses a one-way CHAP
authentication to authenticate the Software Initiator access.
Perform the following settings to enable CHAP authentication.
Procedure
1 Select the [Configuration] tab on VMware Infrastructure Client and select
[Storage Adapters].
2 Select the target iSCSI Software Adapter and click [Properties].
3 Select the [CHAP Authentication] tab and click [Configure].
4 Select the [Use the following CHAP credentials] radio button.
5 Set arbitrary user name during the CHAP authentication.
