Grandstream Networks, Inc. GXW40XX User Manual Page 11 of 38
Firmware 1.0.4.2 Last Updated: 06/2011
BASIC OPERATIONS
UNDERSTANDING GXW VOICE PROMPTS
GXW40XX has a built-in voice prompt menu for simple device configuration. To enter the voice prompt
menu, press *** on the standard analog phone connected to any FXS port.
T
ABLE 5: DEFINITIONS OF THE GXW VOICE PROMPTS
Menu
Voice Prompt
User’s Options
Main Menu
“Enter a Menu Option”
Enter “*” for the next menu option
Enter “#” to return to the main menu
Enter 01 – 05, 07,10 - 17, 47, 86 or 99 Menu option
01
“DHCP Mode”, “PPPoE
Mode ”or “Static IP Mode”
Enter ‘9’ to toggle the selection
If user selects “Static IP Mode”, user need configure all the IP
address information through menu 02 to 05. If user selects
“Dynamic IP Mode”, the device will retrieve all IP address
information from DHCP server automatically when user reboots
the device.
02
“IP Address “ + IP address
The current WAN IP address is announced
Enter 12-digit new IP address if in Static IP Mode.
03
“Subnet “ + IP address
Same as Menu option 02
04
“Gateway “ + IP address
Same as Menu option 02
05
“DNS Server “ + IP address
Same as Menu option 02
07
Preferred Vocoder
Enter “9” to go to the next selection in the list:
• PCM U
• PCM A
• iLBC
• G-726
• G-723
• G-729
10
“MAC Address”
Announces the Mac address of the unit.
12
WAN Port Web Access
Enter “9” to toggle between enabled and disabled
13
Firmware Server IP
Address
Announces current Firmware Server IP address. Enter 12 digit
new IP address.
14
Configuration Server IP
Address
Announces current Config Server Path IP address. Enter 12 digit
new IP address.
15
Upgrade Protocol
Upgrade protocol for firmware and configuration update. Enter
“9” to toggle between
TFTP
and
HTTP
16
Firmware Version
Firmware version information.
17
Firmware Upgrade Firmware upgrade mode. Enter “9” to rotate among the following
three options:
1. always check
2. check when pre/suffix changes
3. never upgrade
47
“Direct IP Calling”
Enter the target IP address to make a direct IP call, after dial
tone. (See “Make a Direct IP Call”.)
71-78
Phone calls between
different ports of the same
GW 400x
Applies to GXW4004/GXW4008. User can make internal calls
between different ports inside the same GW even without being
registered to SIP server. By dialing *** and 7x user can reach
colleague connected to port “x”.
701-724
Phone calls between
different ports of the same
GW4024
Applies to GXW4024. User can make internal calls between
different ports inside the same GW even without being registered
to SIP server. By dialing *** and 7xx user can reach colleague
connected to port “xx”.
86
Voice Mail
Number of voice mails
99
“RESET”
Enter “9” to reboot the device; or
