Grandstream Networks, Inc. GXW40XX User Manual Page 18 of 38
Firmware 1.0.4.2 Last Updated: 06/2011
CONFIGURATION GUIDE
CONFIGURING GXW40XX VIA VOICE PROMPT
DHCP MODE
Select voice menu option 01 to enable GXW40XX to use DHCP.
STATIC
IP MODE
Select voice menu option 01 to enable GXW40XX to use STATIC IP mode, then use option 02, 03, 04, 05
to set up IP address, Subnet Mask, Gateway and DNS server respectively.
F
IRMWARE SERVER IP ADDRESS
Select voice menu option 13 to configure the IP address of the firmware server.
C
ONFIGURATION SERVER IP ADDRESS
Select voice menu option 14 to configure the IP address of the configuration server.
U
PGRADE PROTOCOL
Select voice menu option 15 to choose firmware and configuration upgrade protocol. User can choose
between TFTP and HTTP.
F
IRMWARE UPGRADE MODE
Select voice menu option 17 to choose firmware upgrade mode among the following three options:
1) always check, 2) check when pre/suffix changes, and 3) never upgrade
WAN
PORT WEB ACCESS (Note: This option is not present on GXW4024 gateway)
Select voice menu option 12 to enable WAN Port Wed Access of the device configuration pages.
CONFIGURING GXW40XX WITH WEB BROWSER
The GXW40XX series gateway has an embedded Web server that allows users to configure the
GXW40XX through a web browser.
A
CCESS THE WEB CONFIGURATION MENU
The GXW40XX HTML configuration menu can be accessed via LAN or WAN port:
From the LAN port (For GXW4004/8 only)::
1. Directly connect a computer to the LAN port.
2. In Windows, open a ‘Command Prompt’ window
3. Type in “ipconfig /release”, the IP address etc. becomes 0.
4. Type in “ipconfig /renew”, the computer gets an IP address in 192.168.2.x segment by default
5. Open a web browser, type in the default gateway IP address.
http://192.168.2.1. You will see the
login page of the device.
From the WAN port (For GXW4004/8 only):
The WAN port HTML configuration option is disabled by default from factory. To access the HTML
configuration menu from the WAN port:
1. Follow table 4 to find the WAN side IP address.
2. Open a web browser, type in the WAN side IP address – for example:
http://GXW40XX -IP-
Address (the GXW40XX IP-Address is the WAN IP address for the GXW40XX).
