HandyTone-386 User Manual Grandstream Networks, Inc.
16
End User
Password
This contains the password to access the Web Configuration Menu. This
field is case sensitive.
IP Address
There are 2 modes under which the HandyTone ATA can operate:
- If DHCP mode is enabled, then all the field values for the Static IP mode
are not used (even though they are still saved in the Flash memory.) The
HandyTone ATA will acquire its IP address from the first DHCP server it
discovers from the LAN it is connected.
To use the PPPoE feature the PPPoE account settings need to be set. The
HandyTone will attempt to establish a PPPoE session if any of the PPPoE
fields is set.
- If Static IP mode is enabled, then the IP address, Subnet Mask, Default
Router IP address, DNS Server 1 (primary), DNS Server 2 (secondary) fields
will need to be configured. These fields are reset to zero by default.
Time Zone
This parameter controls how the displayed date/time will be adjusted
according to the specified time zone.
Daylight Savings Time
This parameter controls whether the displayed time will be daylight savings
time or not. If set to Yes, then the displayed time will be 1 hour ahead of
normal time.
In addition to the Basic Settings configuration page, end users also have access to the device Status
page. The following is a snap shot of the device Status page. Details will be explained next.
Grandstream Device Configuration
STATUS BASIC SETTINGS ADVANCED SETTINGS
MAC Address:
00.0B.82.00.00.00
WAN IP Address:
Product Model:
HT386
Software Version:
Program-- 1.0.2.5 Bootloader-- 1.0.1.0 HTML-- 1.0.0.5 VOC-- 1.0.0.10
S
y
stem Up Time:
0 day(s) 4 hour(s) 43 minute(s)
Re
g
istered:
Yes
PPPoE Link Up:
disabled
detected NAT type is symmetric NAT
