HandyTone-386 User Manual Grandstream Networks, Inc.
20
Yes, STUN server is:
stun.mycompany.com
(URI or IP:port)
keep-alive interval:
20
(in seconds, default 20 seconds)
Use NAT IP
(if specified, this IP address is used in SIP/SDP message)
Proxy-
R
equire:
(if specified, the content will appear in Proxy-Require
header)
TFTP Upgrade Server:
19
2
.
16
8
.
1
.
30
(for remote software upgrade and configuration)
SUBSCRIBE for MWI:
No, do not send SUBSCRIBE for Message Waiting Indication
Yes, send periodical SUBSCRIBE for Message Waiting Indication
Offhook Auto-Dial:
(User ID/extension to dial automatically when offhook)
Send Flash Event:
No Yes (Flash will be sent as a DTMF event if set to Yes)
FXS Impedance:
current setting is " 600 Ohm (North America)"
Caller ID Scheme:
current setting is " Bellcore"
Onhook Voltage (FXS
Port):
current setting is " 48V"
Disable Call-Waiting:
No Yes
Polarity Reversal:
No Yes (reverse polarity upon call establishment and termination)
NTP Server:
time.nist.gov
(URI or IP address)
Send Anonymous:
No Yes (caller ID will be blocked if set to Yes)
Lock keypad update:
No Yes (configuration update via keypad is disabled if set to Yes)
PSTN access code:
(key pattern to use the PSTN line, default is "*00")
Syslog Server:
Syslog Level:
current setting is "NONE"
Cancel
Update
Reboot
All Rights Reserved Grandstream Networks, Inc. 2004
Admin Password
This contains the password to access the Advanced Web Configuration page.
This field is case sensitive.
SIP Server
SIP Server’s URI or IP address
Outbound Proxy
SIP Outbound Proxy Server’s URI or IP address
