Product Description
Maintenance and Service Guide 1–7
Table 1-1
Front Components
Item Component Function
1 Speakers (2) Produce stereo sound.
2 Wireless light (select
models only)
On: An integrated wireless device is
hardware enabled.
3 Power/standby light
■ On: Notebook is turned on.
■ Blinking: Notebook is in standby.
■ Off: Notebook is off or in hibernation.
4 IDE (Integrated Drive
Electronics) drive light
■ On or blinking: The internal hard drive
or an optical drive is being accessed.
5Battery light
■ Amber: The battery pack is charging.
■ Green: The battery pack is fully
charged.
■ Off: The battery pack is discharging
or not inserted.
6 Display release latch Opens the notebook.
7Audio-in
(microphone) jack
Connects an optional monaural (single
sound channel) microphone.
8Audio-out
(headphone) jack
Connect optional headphones or powered
stereo speakers. Also connect the audio
function of an audio/video device such as
a television or VCR.
