Removal and Replacement Procedures
Maintenance and Service Guide 5–3
5.2 Disassembly Sequence Chart
Use the chart below to determine the section number to be
referenced when removing notebook components.
Disassembly Sequence Chart
Section Description
# of Screws Removed
5.3 Preparing the Notebook
for Disassembly
Battery pack 0
5.4 Hard Drive 2 loosened to remove the hard
drive cover
4 removed to disassemble the
hard drive
5.5 Notebook Feet 0
5.6 Memory Module 2 loosened to remove the
memory module compartment
cover
5.7 Mini PCI Communications
Module
1 loosened to remove the
Mini PCI compartment cover
Ä
To prevent an unresponsive system and the display of a
warning message, install only a Mini PCI device authorized
for use in your notebook by the governmental agency that
regulates wireless devices in your country. If you install a
device and then receive a warning message, remove the
device to restore notebook functionality. Then contact
Customer Care.
5.8 Optical Drive 1
5.9 Switch Cover 2
5.10 Keyboard 4
