Removal and Replacement Procedures
Maintenance and Service Guide 5–47
5.20 LED Board
✎
1. Prepare the notebook for disassembly (Section 5.3) and
remove the following components:
❏ Optical drive (Section 5.8)
❏ Switch cover (Section 5.9)
❏ Keyboard (Section 5.10)
❏ Display assembly (Section 5.11)
❏ Base enclosoure (Section 5.12)
❏ USB/S-Video controller board (Section 5.13)
❏ Speaker assembly (Section 5.15)
❏ System board (Section 5.19)
2. Turn the notebook upside down with the front toward you.
LED Board Spare Part Number Information
LED board (includes cable) 394374-001
