1–2 Maintenance and Service Guide
Product Description
1.1 Features
✎
Numerous references are made throughout this Maintenance
and Service Guide to “full-featured” and “defeatured” units. A
notebook model is considered to be full-featured if it has
3 Universal Serial Bus ports and the following components:
■ 6-in-1 digital card reader
■ Expansion port 2
■ Bluetooth wireless communications support
■ IEEE 1394 digital port
A notebook model is considered to be defeatured if it has only
2 Universal Serial Bus ports and none of the components in the
preceding list.
■ The following processors are available, varying by
notebook model:
❏ AMD Turion 64 ML-37 (2.0-GHz), ML-34 and ML-32
(1.8-GHz), and ML-30 and ML-28 (1.6-GHz) processors
❏ Mobile AMD Sempron 3300+ (2.0-GHz), 3000+
(1.8-GHz), and 2800+ (1.6-GHz) processors
■ 14.0-inch WXGA (1280 × 768) TFT display with over
16.7 million colors, varying by notebook model
■ 100-, 80-, 60-, or 40-GB high-capacity hard drive, varying by
notebook model
■ 256-MB DDR synchronous DRAM (SDRAM) at 333 MHz,
expandable to 2.0 GB on select models
■ Microsoft® Windows® XP Home Edition or Windows XP
Professional, varying by notebook model
■ Full-size Windows keyboard with embedded numeric keypad
■ TouchPad pointing device with on/off button and dedicated
two-way scroll region
